Thus, the output for the above command will be:
Resultant Table
Rollno Name Fee
2 Jaya 5500
3 Teena 5000
4 Diksha 4500

2. Outer Join: The Outer Join keyword returns all rows from the right table (table 2), with the
matching rows in the left table (table 1). The result is NULL in the left side when there is no
match.
mysql> SELECT A.Rollno, Name, fee

FROM student A, fees B WHERE
OUTER JOIN
A.Rollno = B.Rollno ORDER BY B.fee desc;
Resultant Table
Rollno Name Fee
2 Jaya 5500 table 1 table 2
3 Teena 5000
4 Diksha 4500
Note: Self, Non-equi and Natural join are beyond the scope of this book.

Let us take an example of two tables to explain the concept of MySQL Joins: (Question taken
from CBSE 2015-16 Board Paper)
Table: Vehicle

CODE VTYPE PERKM
101 VOLVO BUS 160
102 AC DELUXE BUS 150
103 ORDINARY BUS 90
105 SUV 40
104 CAR 20

Note:

• PERKM is Freight Charges per kilometre
• VTYPE is Vehicle Type
Table: Travel

NO NAME TDATE KM CODE NOP
101 Janish Kin 2015–11–13 200 101 32
103 Vedika Sahai 2016–04–21 100 103 45
Relational Database and SQL
105 Tarun Ram 2016–03–23 350 102 42
102 John Fen 2016–02–13 90 102 40
107 Ahmed Khan 2015–01–10 75 104 2
104 Raveena 2016–05–28 80 105 4

12.49
