HYDERABAD                        NOIDA

                   ADMIN
                                   TARGET
                                   AUDIENCE
                   SALES                                   HEAD
                                   PRODUCT                OFFICE
                                   CATEGORIES
                 MATERIAL


                Block-to-block distances (in metres):
                From           To                           Distance
                ADMIN          SALES                        50
                ADMIN          TARGET AUDIENCE              65
                ADMIN          MATERIAL                     44
                ADMIN          PRODUCT CATEGORIES           56
                SALES          MATERIAL                     75
                SALES          PRODUCT CATEGORIES           90
                MATERIAL       PRODUCT CATEGORIES           25
                MATERIAL       TARGET AUDIENCE              68

                Distance between Noida head office and Hyderabad campus = 1550 km
                Number of computers in each block is as follows:

                ADMIN                                     50
                SALES                                     15
                MATERIAL                                  25
                TARGET AUDIENCE                           08
                PRODUCT CATEGORIES                        20
                NOIDA HEAD OFFICE                         36
                (a)  Suggest the most appropriate location of the server inside the Hyderabad campus. Justify your choice.
                (b)  Which hardware device will you suggest to connect all the computers within each building?
                (c)  Draw the cable layout to efficiently connect various building within the Hyderabad campus. Which cable
                   would you suggest for the most efficient data transfer over the network?
                (d)  Is there any requirement of a repeater in the given cable layout? Give reasons for your answer.
                (e)  (i)  What would be your recommendation for enabling live visual communication between the Admin
                       Office at the Hyderabad campus and the Noida head office from the following options:
                          I.  Videoconferencing
                         II.  Instant Messaging
                         III.  Email
                         IV.  Telephony
                                                          OR
                    (ii)  Which type of network (PAN, LAN, MAN or WAN) will be set up among the computers connected in the
                       Hyderabad campus?













          A.52                                                           Computer Science with Python–XII
